DMX-512 MASTER · OFFLINE CONTROLLER
Standalone DMX-512 Master Controller
A DMX-512 master controller that runs standalone — no computer required. A reliable, easy-to-install solution for stage, architectural and event lighting.
1× Universe512 ChannelsStandaloneDMX-512
WHY KAMINO
Key Features
Standalone Operation
No PC or software needed; the device runs on its own, uninterrupted.
512 DMX Channels
Precisely manage 512 channels on a single universe.
Scene Memory
Save your scenes and recall them instantly with one touch.
Easy Setup
Clean interface and quick mounting — up and running in minutes.
SPECIFICATION
Technical Specs
ProtocolDMX-512 (Master)
Universe1× (512 channels)
Outputs2 fully isolated DMX-512 outputs (3-pin screw terminals)
Operation ModeOffline / Standalone
ControlBuilt-in interface · Scene memory · 1 button (scene select)
PC ConnectionUSB 2.0 Type B (scenario upload with Argetron software)
Input Voltage12–48 Vdc
Power Consumption< 1 W
TerminationJumper-selectable termination resistor
Dimensions (W×H×D)120 × 24 × 55 mm
Weight112 g
HousingAluminium, non-conductive, non-flammable · IP20
MountingFlat body
Operating Temperature-20 … +50 °C
Humidity0 … 80% (non-condensing)
Electrical SafetySELV
CertificateCE
DOWNLOAD
Documents
Product Brochure
KAMINO technical brochure (PDF, EN).
User Manual
DMX-512 Master user manual (PDF).
APPLICATION AREAS
Where It Is Used
Architectural Lighting
Indoor and facade architectural lighting scenarios.
Stage & Concert
Stage, concert and show lighting control.
Event & Expo
Event, expo and booth lighting.
Facade & Landscape
Facade, landscape and outdoor lighting.
CONTACT
Is Kamino right for your project?
Our technical team helps you choose the most suitable controllers and drivers for your setup.
